Wilo Para MAXO 25-180-08-F02 VAL 2211051

Reconditioned electronically controlled circulator pump head for heating and solar applications. Head only, no complete pump body included.

Product Details

• Article number: 2211051
• Model: Wilo Para MAXO 25-180-08-F02 VAL
• Product type: Glandless, electronically controlled circulator pump head
• Function: Circulates water through the heating or brine circuit while the ECM motor and electronic control adjust pump output to match demand. Variable differential-pressure control maintains the required flow with lower energy use and noise, while the blocking-current-proof motor and maintenance-free glandless design support reliable operation
• Maximum head: 8.2 metres
• Maximum flow: 9.5 m³/h
• Operating pressure: Up to 10 bar
• Fluid temperature: -20°C to +110°C
• Ambient temperature: -20°C to +70°C
• Power supply: 1~230V, 50/60 Hz
• Rated power: P2 90 W
• Maximum power consumption: P1 max 128 W
• Maximum speed: 3500 rpm
• Energy efficiency index: EEI ≤ 0.20
• Protection rating: IPX4D
• Insulation class: F
• Condition: Reconditioned
• Brand: Wilo

Compatibility

• IVT Greenline C5-C9 kW
• IVT Greenline HT C/E 6-17 kW
• IVT HA C/E 6-17 kW
• Bosch Compress EHP 6-17 kW
• Bosch Compress 3500 6-14 kW
• Vaillant flexoTHERM exclusive

This listing is for the pump head only. Check the model, article number, mounting interface, control face and electrical rating against the existing pump before ordering.
